W01-M58-6140 1/4 BSP Air Hole Firestone Industrial Single Type Air Shock Suspension
Product Description
Air springs are extremely durable, precisely engineered, and cost-effective for a variety of actuation and vibration isolation applications. With their proven design, fabric-reinforced neoprene or natural rubber flex member construction, and corrosion-resistant end retainers, air springs offer superior quality and performance. As isolators, air springs effectively reduce the harmful effects of vibration. They can simultaneously isolate vibration and adjust load height, allowing for consistent vibration isolation at varying loads.
OEM Cross References
Firestone Air Bellow W01-M58-6140
Firestone Air Bellow W01M586140
Firestone Air Bellow W01 M58 6140
Continental Contitech FS 50-5
Continental Contitech FS 505
Continental Contitech FS 50 5
Product Information
Bottom Plate Alignment: Parallel
Bottom Plate Center To Center Diameter: 44 mm
Bottom Plate Diameter: 114 mm
Bottom Plate Hole Quantity: 2×M8×1.25
Bottom Plate Type: Steel |
Top Plate Alignment: Parallel
Top Plate Center To Center Diameter: 44 mm
Top Plate Diameter: 114 mm
Top Plate Hole Quantity: 2×M8×1.25
Top Plate Type: Steel |
Expanded Height: 89 mm
Compressed Height: 48 mm
Spring Type: Single Convoluted
Nut/Blind Nuts Type: 2×M8×1.25
Max Rubber Bellow Diameter: 152 mm |
| Air Connection: 1/4 BSP
Operation: Gas-filled |
Other Types of Industrial Convoluted Rubber Air Springs
| OEM Number | Style | OEM Number | Style |
| W01-358-7325 | STYLE 26 | W01-358-7327 | STYLE 26 |
| W01-358-7333 | STYLE 26 | W01-358-7400 | STYLE 22 |
| W01-358-7431 | STYLE 22 | W01-358-7442 | STYLE 22-1.5 |
| W01-358-7443 | STYLE 22-1.5 | W01-358-7444 | STYLE 22-1.5 |
| W01-358-7451 | STYLE 110 | W01-358-7458 | STYLE 115 |
| W01-358-7459 | STYLE 115 | W01-358-7460 | STYLE 115 |
| W01-358-7465 | STYLE 115 | W01-358-7469 | STYLE 115 |
| W01-358-7473 | STYLE 22-1.5 | W01-358-7477 | STYLE 119 |
| W01-358-7478 | STYLE 119 | W01-358-7558 | STYLE 233-2 |
| W01-358-7561 | STYLE 116 | W01-358-7564 | STYLE 116 |
| W01-358-7568 | STYLE 116 | W01-358-7592 | STYLE 160 |
| W01-358-7598 | STYLE 116-1 | W01-358-7600 | STYLE 117 |
| W01-358-7602 | STYLE 117 | W01-358-7605 | STYLE 116-1 |
| W01-358-7606 | STYLE 117 | W01-358-7649 | STYLE 124 |
| W01-358-7650 | STYLE 124 | W01-358-7726 | STYLE 126 |
| W01-358-7727 | STYLE 126 | W01-358-7729 | STYLE 131 |
| W01-358-7731 | STYLE 131 | W01-358-7734 | STYLE 138-1.5 |
| W01-358-7737 | STYLE 138-1.5 | W01-358-7742 | STYLE 131 |
